Toyota returns to motorsport with GT86 CS-R3

260115toy-CS-R3_111214_JB_0215

Toyota is preparing for its motorsport come back later this year with the GT86 CS-R3.

The brand’s motorsport arm, Toyota Motorsport has announced development work on the racecar is well underway. Launched in prototype form last August, the GT86 CS-R3 has since undergone an extensive test programme to fine-tune its design.

260115toy-CS-R3_101214_JB_0103

The company says the development work has improved performance on both gravel and tarmac, together with reliability and durability in order to deliver a car that can be used for low-cost competition for a full season and beyond.

The first cars will be delivered to private competitors and teams in May, slightly later than originally forecast to allow time for improvements identified during testing to be fully implemented.

260115toy-CS-R3_091214_JB_0014

The kit includes a GT86 body shell, powertrain and all the mechanical components required to build the car.

The car will be homologated to FIA R3 regulations at the beginning of July, after which all CS-R3 cars will be eligible for international rally competitions, up to and including the World Rally Championship.

The GT86 CS-R3 is expected to make its competition debut at the Rally Niedersachsen in Germany on 4 July, with up to 10 cars due to take part. This will be the first round of the new HJS Toyota Motorsport CS-R3 Trophy. The series will be contested over seven rounds, with more than €5,000 in prize money available at each event. The trophy will run for at least the next three seasons.

GT86 CS-R3 Technical Specifications

ENGINE
CodeFA20
LayoutBoxer/flat four
Displacement (cc)1,998
Max. power (bhp)235 (173kW)
Max. torque (Nm @ rpm)230 @ 6,800
TRANSMISSION
TypeRear-wheel drive
GearboxDrenth six-speed sequential
DifferentialLimited-slip with ramp setting options
Final driveShort final drive, with options
ClutchRacing clutch with lightweight flywheel
SUSPENSION
FrontMacPherson-type
RearMulti-link
Shock absorbersReiger three-way adjustable for gravel or tarmac
Anti-roll barOptions available
BRAKES
Front (mm)Gravel: 300 x 30
Tarmac: 330 x 30
Rear (mm)Gravel: 295 x 10
Tarmac: 295 x 10
CalipersFront: Alcon four-piston
Rear: Alcon two-piston
WHEELS
GravelOZ 6 x15in
TarmacOZ 7 x 17in
DIMENSIONS & WEIGHT
Length (mm)4,240
Width (mm)1,775
Wheelbase (mm)2,570
Weight (kg)1,080 (by regulation)
CHASSIS
Body shellSteel monocoque with roof vent
Roll cageHomologated R3
OTHER TECHNICAL FEATURES
ExhaustHJS racing exhaust and manifold
Fuel cellFT3 safety cell
SteeringHydraulic power steering with short ratio
